Server Resellers
|
Type
|
Oem Supported Server Storage Ram Nas Rack Internet Server 2288Hv7 2288Hv6
|
|
Form Factor
|
2U Rack Server
|
|
Processor
|
1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W
1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W |
|
PCIe Expansion
|
Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC
|
|
Memory
|
24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s
|
|
Network Ports
|
LOM: 2 x 10 GE + 2 x GE ports
Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, 2 x 25 GE, or 1/2 x 56G FDR IB ports |
|
Internal Storage
|
Supports hot-pluggable drives with the following configuration options:
8 x 2.5-inch SAS/SATA HDDs or SSDs 12/16/20 x 3.5-inch SAS/SATA HDDs 4, 8, 12, 24, or 28 NVMe SSDs 31 x 2.5-inch SAS/SATA HDDs or SSDs Flash storage: 2 M.2 SSDs |
|
RAID Support
|
RAID 0, 1, 10, 1E, 5, 50, 6, or 60
Configured with a supercapacitor for cache power-off protection (optional) RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration |
|
Heterogeneous Accelerator Card
|
Up to 7 single-width half-height half-length accelerator cards
Up to 2 dual-width full-height full-length accelerator cards |
|
Dimensions (H x W x D)
|
Chassis with 3.5-inch hard drives: 86.1 mm x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.)
Chassis with 2.5-inch hard drives: 86.1 mm x 447 mm x 708 mm (3.39 in. x 17.60 in. x 27.87 in.) |
|
OEM-ready version available
|
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
|
